Name: TLE4267SNKSA1
Brand: Infineon Technologies
SKU: TLE4267SNKSA1
Availability: InStock

REF: TLE4267SNKSA1 Infineon Technologies

TLE4267SNKSA1

IC REG LIN 5V 400MA TO220-7-12

TLE4267SNKSA1 is a PMIC - Voltage Regulators - Linear manufactured by Infineon Technologies. IC REG LIN 5V 400MA TO220-7-12. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 150°C, package / case TO-220-7, current - supply (max) 80 mA.

Datasheet Request a Quote

In Stock: 7,407

Specifications

18 parameters

Product Status	Obsolete
Output Configuration	Positive
Output Type	Fixed
Number of Regulators	1
Voltage - Input (Max)	40V
Voltage - Output (Min/Fixed)	5V
Voltage - Output (Max)	-
Voltage Dropout (Max)	0.6V @ 400mA
Current - Output	400mA

Current - Quiescent (Iq)	4 mA
Current - Supply (Max)	80 mA
PSRR	54dB (100Hz)
Control Features	Inhibit, Reset
Protection Features	Over Temperature, Over Voltage, Reverse Polarity, Short Circuit, Transient Voltage
Operating Temperature	-40°C ~ 150°C
Mounting Type	Through Hole
Package / Case	TO-220-7
Supplier Device Package	PG-TO220-7-12
