Name: IPA65R660CFDXKSA2
Brand: Infineon Technologies
SKU: IPA65R660CFDXKSA2
Price: 1.34 USD
Availability: InStock

REF: IPA65R660CFDXKSA2 Infineon Technologies

IPA65R660CFDXKSA2

Infineon Technologies

MOSFET N-CH 700V 6A TO220

IPA65R660CFDXKSA2 is a Transistors - FETs, MOSFETs - Single manufactured by Infineon Technologies. MOSFET N-CH 700V 6A TO220. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 150°C (TJ), package / case TO-220-3 Full Pack.

Datasheet Request a Quote

In Stock: 7,555

Specifications

17 parameters

Product Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	700 V
Current - Continuous Drain (Id) @ 25°C	6A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	660mOhm @ 2.1A, 10V
Vgs(th) (Max) @ Id	4.5V @ 200µA
Gate Charge (Qg) (Max) @ Vgs	22 nC @ 10 V

Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	615 pF @ 100 V
FET Feature	-
Power Dissipation (Max)	27.8W (Tc)
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Through Hole
Supplier Device Package	PG-TO220 Full Pack
Package / Case	TO-220-3 Full Pack
