Name: IPA60R160P7XKSA1
Brand: Infineon Technologies
SKU: IPA60R160P7XKSA1
Price: 3.80 USD
Availability: InStock

REF: IPA60R160P7XKSA1 Infineon Technologies

IPA60R160P7XKSA1

Infineon Technologies

MOSFET N-CH 600V 20A TO220

IPA60R160P7XKSA1 is a Transistors - FETs, MOSFETs - Single manufactured by Infineon Technologies. MOSFET N-CH 600V 20A TO220. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 150°C (TJ), package / case TO-220-3 Full Pack.

Datasheet Request a Quote

In Stock: 4,564

Specifications

17 parameters

Product Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	600 V
Current - Continuous Drain (Id) @ 25°C	20A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	160mOhm @ 6.3A, 10V
Vgs(th) (Max) @ Id	4V @ 350µA
Gate Charge (Qg) (Max) @ Vgs	31 nC @ 10 V

Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	1317 pF @ 400 V
FET Feature	-
Power Dissipation (Max)	26W (Tc)
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Through Hole
Supplier Device Package	PG-TO220 Full Pack
Package / Case	TO-220-3 Full Pack
