Name: ESD234B1W0201E6327XTSA1
Brand: Infineon Technologies
SKU: ESD234B1W0201E6327XTSA1
Price: 0.12 USD
Availability: InStock

REF: ESD234B1W0201E6327XTSA1 Infineon Technologies

ESD234B1W0201E6327XTSA1

Infineon Technologies

TVS DIODE 5.5VWM 12VC WLL-2-1

ESD234B1W0201E6327XTSA1 is a TVS - Diodes manufactured by Infineon Technologies. TVS DIODE 5.5VWM 12VC WLL-2-1. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 125°C (TA), package / case 0201 (0603 Metric).

Datasheet Request a Quote

In Stock: 13,449

Tiered Pricing USD

1+ $0.1200 —

10+ $0.0810 -33%

100+ $0.0400 -67%

500+ $0.0395 -67%

1,000+ $0.0387 -68%

2,000+ $0.0327 -73% BEST

Specifications

16 parameters

Product Status	Active
Type	Zener
Unidirectional Channels	-
Bidirectional Channels	1
Voltage - Reverse Standoff (Typ)	5.5V
Voltage - Breakdown (Min)	7.5V
Voltage - Clamping (Max) @ Ipp	12V (Typ)
Current - Peak Pulse (10/1000µs)	7A (8/20µs)

Power - Peak Pulse	84W
Power Line Protection	No
Applications	General Purpose
Capacitance @ Frequency	56pF @ 1MHz
Operating Temperature	-55°C ~ 125°C (TA)
Mounting Type	Surface Mount
Package / Case	0201 (0603 Metric)
Supplier Device Package	WLL-2-1
