6ED2230S12TXUMA1

In Stock: 2,818
6ED2230S12TXUMA1 - Infineon Technologies - PMIC - Gate Drivers
REF: 6ED2230S12TXUMA1 Infineon Technologies
6ED2230S12TXUMA1

Infineon Technologies

1200V THREE PHASE DRIVER

6ED2230S12TXUMA1 is a PMIC - Gate Drivers manufactured by Infineon Technologies. 1200V THREE PHASE DRIVER. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C (TA), voltage - supply 10V ~ 20V, package / case 28-SOIC (0.295", 7.50mm Width), 24 Leads.

Datasheet Request a Quote

In Stock: 2,818

Tiered Pricing USD
1+ $4.0900 —
10+ $3.0930 -24%
25+ $2.8444 -30%
100+ $2.5708 -37%
250+ $2.4404 -40%
500+ $2.3617 -42% BEST

Specifications

15 parameters
Product StatusActive
Driven ConfigurationHigh-Side or Low-Side
Channel Type3-Phase
Number of Drivers6
Gate TypeIGBT, N-Channel MOSFET
Voltage - Supply10V ~ 20V
Logic Voltage - VIL, VIH0.7V, 2.3V
Current - Peak Output (Source, Sink)350mA, 650mA
Input TypeInverting
High Side Voltage - Max (Bootstrap)1200 V
Rise / Fall Time (Typ)35ns, 20ns
Operating Temperature-40°C ~ 125°C (TA)
Mounting TypeSurface Mount
Package / Case28-SOIC (0.295", 7.50mm Width), 24 Leads
Supplier Device PackagePG-DSO-24
