2ED24427N01FXUMA1

In Stock: 1,019
2ED24427N01FXUMA1 - Infineon Technologies - PMIC - Gate Drivers
REF: 2ED24427N01FXUMA1 Infineon Technologies
2ED24427N01FXUMA1

Infineon Technologies

LOW SIDE DRIVERS

2ED24427N01FXUMA1 is a PMIC - Gate Drivers manufactured by Infineon Technologies. LOW SIDE DRIVERS. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C (TA), voltage - supply 5V ~ 20V, package / case 8-SOIC (0.154", 3.90mm Width) Exposed Pad.

Datasheet Request a Quote

In Stock: 1,019

Specifications

15 parameters
Product StatusActive
Driven ConfigurationLow-Side
Channel TypeIndependent
Number of Drivers2
Gate TypeN-Channel MOSFET
Voltage - Supply5V ~ 20V
Logic Voltage - VIL, VIH0.8V, 2.5V
Current - Peak Output (Source, Sink)10A, 10A
Input TypeNon-Inverting
High Side Voltage - Max (Bootstrap)-
Rise / Fall Time (Typ)-
Operating Temperature-40°C ~ 125°C (TA)
Mounting TypeSurface Mount
Package / Case8-SOIC (0.154", 3.90mm Width) Exposed Pad
Supplier Device PackagePG-DSO-8-900
