Name: 2ED020I12FIXUMA1
Brand: Infineon Technologies
SKU: 2ED020I12FIXUMA1
Price: 2.96 USD
Availability: InStock

REF: 2ED020I12FIXUMA1 Infineon Technologies

2ED020I12FIXUMA1

Infineon Technologies

IC GATE DRVR HALF-BRIDGE DSO18-2

2ED020I12FIXUMA1 is a PMIC - Gate Drivers manufactured by Infineon Technologies. IC GATE DRVR HALF-BRIDGE DSO18-2. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 150°C (TJ), voltage - supply 14V ~ 18V, package / case 18-SOIC (0.295", 7.50mm Width).

Datasheet Request a Quote

In Stock: 4,177

Tiered Pricing USD

1+ $2.9600 —

10+ $2.2120 -25%

25+ $2.0256 -32%

100+ $1.8206 -38%

250+ $1.7229 -42%

500+ $1.6640 -44% BEST

Specifications

15 parameters

Product Status	Active
Driven Configuration	Half-Bridge
Channel Type	Independent
Number of Drivers	2
Gate Type	IGBT, N-Channel MOSFET
Voltage - Supply	14V ~ 18V
Logic Voltage - VIL, VIH	0.8V, 2V
Current - Peak Output (Source, Sink)	1A, 2A

Input Type	Inverting
High Side Voltage - Max (Bootstrap)	1200 V
Rise / Fall Time (Typ)	20ns, 20ns
Operating Temperature	-40°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	18-SOIC (0.295", 7.50mm Width)
Supplier Device Package	PG-DSO-18-2
