Name: ESP32-D2WD
Brand: Espressif Systems
SKU: ESP32-D2WD
Availability: InStock

REF: ESP32-D2WD Espressif Systems

ESP32-D2WD

IC RF TXRX+MCU BLUETOOTH 48VFQFN

ESP32-D2WD is a RF Transceiver ICs manufactured by Espressif Systems. IC RF TXRX+MCU BLUETOOTH 48VFQFN. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, voltage - supply 2.3V ~ 3.6V, package / case 48-VFQFN Exposed Pad.

Datasheet Request a Quote

In Stock: 8,088

Specifications

19 parameters

Product Status	Obsolete
Type	TxRx + MCU
RF Family/Standard	Bluetooth, WiFi
Protocol	802.11b/g/n, Bluetooth 4.2
Modulation	CCK, DSSS, OFDM
Frequency	2.4GHz
Data Rate (Max)	150Mbps
Power - Output	20dBm
Sensitivity	-98dBm
Memory Size	16Mb Flash, 448kB ROM, 520kB SRAM

Serial Interfaces	I²C, I²S, SPI, UART
GPIO	34
Voltage - Supply	2.3V ~ 3.6V
Current - Receiving	100mA
Current - Transmitting	240mA
Operating Temperature	-40°C ~ 125°C
Mounting Type	Surface Mount
Package / Case	48-VFQFN Exposed Pad
Supplier Device Package	48-QFN (5x5)
