Name: 9001-075
Brand: E-T-A
SKU: 9001-075
Availability: InStock

REF: 9001-075 E-T-A

9001-075

SENSOR CURRENT SWITCH 75A DC

9001-075 is a Current Sensors manufactured by E-T-A. SENSOR CURRENT SWITCH 75A DC. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 125°C, voltage - supply 3.8V ~ 24V, package / case Module, Single Board Pass Through.

Datasheet Request a Quote

In Stock: 3,189

Specifications

18 parameters

Product Status	Obsolete
For Measuring	DC
Sensor Type	Current Switch
Current - Sensing	75A
Number of Channels	1
Output	Open Collector
Sensitivity	-
Frequency	-
Linearity	-

Accuracy	-
Voltage - Supply	3.8V ~ 24V
Response Time	1µs
Current - Supply (Max)	10mA
Operating Temperature	-40°C ~ 125°C
Polarization	Unidirectional
Mounting Type	Through Hole
Package / Case	Module, Single Board Pass Through
Supplier Device Package	-
