DMN2024UVT-13

In Stock: 2,403
DMN2024UVT-13 - Diodes Incorporated - Transistors - FETs, MOSFETs - Arrays
REF: DMN2024UVT-13 Diodes Incorporated
DMN2024UVT-13

Diodes Incorporated

MOSFET BVDSS: 8V-24V TSOT26

DMN2024UVT-13 is a Transistors - FETs, MOSFETs - Arrays manufactured by Diodes Incorporated. MOSFET BVDSS: 8V-24V TSOT26. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 150°C (TJ), package / case SOT-23-6 Thin, TSOT-23-6, power - max 1W.

Datasheet Request a Quote

In Stock: 2,403

Specifications

14 parameters
Product StatusActive
FET Type2 N-Channel (Dual) Common Drain
FET FeatureStandard
Drain to Source Voltage (Vdss)20V
Current - Continuous Drain (Id) @ 25°C7A (Ta)
Rds On (Max) @ Id, Vgs24mOhm @ 6.5A, 4.5V
Vgs(th) (Max) @ Id900mV @ 250µA
Gate Charge (Qg) (Max) @ Vgs7.1nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds647pF @ 10V
Power - Max1W
Operating Temperature-55°C ~ 150°C (TJ)
Mounting TypeSurface Mount
Package / CaseSOT-23-6 Thin, TSOT-23-6
Supplier Device PackageTSOT-23-6
