DMC2710UVT-7

In Stock: 3,814
DMC2710UVT-7 - Diodes Incorporated - Transistors - FETs, MOSFETs - Arrays
REF: DMC2710UVT-7 Diodes Incorporated
DMC2710UVT-7

Diodes Incorporated

MOSFET BVDSS: 8V-24V TSOT26

DMC2710UVT-7 is a Transistors - FETs, MOSFETs - Arrays manufactured by Diodes Incorporated. MOSFET BVDSS: 8V-24V TSOT26. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 150°C (TJ), package / case SOT-23-6 Thin, TSOT-23-6, power - max 500mW (Ta).

Datasheet Request a Quote

In Stock: 3,814

Specifications

14 parameters
Product StatusActive
FET TypeN and P-Channel Complementary
FET FeatureStandard
Drain to Source Voltage (Vdss)20V
Current - Continuous Drain (Id) @ 25°C1.2A (Ta), 900mA (Ta)
Rds On (Max) @ Id, Vgs400mOhm @ 600mA, 4.5V, 700mOhm @ 430mA, 4.5V
Vgs(th) (Max) @ Id1V @ 250µA
Gate Charge (Qg) (Max) @ Vgs600pC @ 4.5V, 700pC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds42pF @ 16V, 49pF @ 16V
Power - Max500mW (Ta)
Operating Temperature-55°C ~ 150°C (TJ)
Mounting TypeSurface Mount
Package / CaseSOT-23-6 Thin, TSOT-23-6
Supplier Device PackageTSOT-23-6
