DMC25D0UVT-13

In Stock: 8,147
DMC25D0UVT-13 - Diodes Incorporated - Transistors - FETs, MOSFETs - Arrays
REF: DMC25D0UVT-13 Diodes Incorporated
DMC25D0UVT-13

Diodes Incorporated

MOSFET N/P-CH 25V/30V TSOT26

DMC25D0UVT-13 is a Transistors - FETs, MOSFETs - Arrays manufactured by Diodes Incorporated. MOSFET N/P-CH 25V/30V TSOT26. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 150°C (TJ), package / case SOT-23-6 Thin, TSOT-23-6, power - max 1.2W.

Datasheet Request a Quote

In Stock: 8,147

Specifications

14 parameters
Product StatusActive
FET TypeN and P-Channel
FET FeatureStandard
Drain to Source Voltage (Vdss)25V, 30V
Current - Continuous Drain (Id) @ 25°C400mA, 3.2A
Rds On (Max) @ Id, Vgs4Ohm @ 400mA, 4.5V
Vgs(th) (Max) @ Id1.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs0.7nC @ 8V
Input Capacitance (Ciss) (Max) @ Vds26.2pF @ 10V
Power - Max1.2W
Operating Temperature-55°C ~ 150°C (TJ)
Mounting TypeSurface Mount
Package / CaseSOT-23-6 Thin, TSOT-23-6
Supplier Device PackageTSOT-23-6
