Name: DMC2038LVTQ-7
Brand: Diodes Incorporated
SKU: DMC2038LVTQ-7
Price: 0.50 USD
Availability: InStock

REF: DMC2038LVTQ-7 Diodes Incorporated

DMC2038LVTQ-7

Diodes Incorporated

MOSFET BVDSS: 8V 24V TSOT26

DMC2038LVTQ-7 is a Transistors - FETs, MOSFETs - Arrays manufactured by Diodes Incorporated. MOSFET BVDSS: 8V 24V TSOT26. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 150°C (TJ), package / case SOT-23-6 Thin, TSOT-23-6, power - max 800mW (Ta).

Datasheet Request a Quote

In Stock: 4,834

Specifications

14 parameters

Product Status	Not For New Designs
FET Type	N and P-Channel Complementary
FET Feature	Logic Level Gate, 1.8V Drive
Drain to Source Voltage (Vdss)	20V
Current - Continuous Drain (Id) @ 25°C	3.7A (Ta), 2.6A (Ta)
Rds On (Max) @ Id, Vgs	35mOhm @ 4A, 4.5V, 74mOhm @ 3A, 4.5V
Vgs(th) (Max) @ Id	1V @ 250µA

Gate Charge (Qg) (Max) @ Vgs	5.7nC @ 4.5V, 10nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds	530pF @ 10V, 705pF @ 10V
Power - Max	800mW (Ta)
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	SOT-23-6 Thin, TSOT-23-6
Supplier Device Package	TSOT-23-6
