Name: AP5725WUG-7
Brand: Diodes Incorporated
SKU: AP5725WUG-7
Price: 0.51 USD
Availability: InStock

REF: AP5725WUG-7 Diodes Incorporated

AP5725WUG-7

IC LED DRVR RGLTR PWM TSOT23-6

AP5725WUG-7 is a PMIC - LED Drivers manufactured by Diodes Incorporated. IC LED DRVR RGLTR PWM TSOT23-6. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C (TA), voltage - output 26V, package / case SOT-23-6 Thin, TSOT-23-6.

Datasheet Request a Quote

In Stock: 1,094

Tiered Pricing USD

1+ $0.5100 —

10+ $0.3610 -29%

25+ $0.3232 -37%

100+ $0.2808 -45%

250+ $0.2607 -49%

500+ $0.2486 -51%

1,000+ $0.2386 -53% BEST

Specifications

16 parameters

Product Status	Active
Type	DC DC Regulator
Topology	Step-Up (Boost)
Internal Switch(s)	Yes
Number of Outputs	1
Voltage - Supply (Min)	2.7V
Voltage - Supply (Max)	5.5V
Voltage - Output	26V

Current - Output / Channel	750mA (Switch)
Frequency	1.2MHz
Dimming	PWM
Applications	Backlight
Operating Temperature	-40°C ~ 85°C (TA)
Mounting Type	Surface Mount
Package / Case	SOT-23-6 Thin, TSOT-23-6
Supplier Device Package	TSOT-23-6
