Name: AP5724WUG-7
Brand: Diodes Incorporated
SKU: AP5724WUG-7
Price: 0.54 USD
Availability: InStock

REF: AP5724WUG-7 Diodes Incorporated

AP5724WUG-7

IC LED DRVR RGLTR PWM TSOT23-6

AP5724WUG-7 is a PMIC - LED Drivers manufactured by Diodes Incorporated. IC LED DRVR RGLTR PWM TSOT23-6. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C (TA), package / case SOT-23-6 Thin, TSOT-23-6, current - output / channel 750mA (Switch).

Datasheet Request a Quote

In Stock: 3,818

Tiered Pricing USD

1+ $0.5400 —

10+ $0.3830 -29%

25+ $0.3424 -37%

100+ $0.2982 -45%

250+ $0.2770 -49%

500+ $0.2642 -51%

1,000+ $0.2537 -53% BEST

Specifications

16 parameters

Product Status	Active
Type	DC DC Regulator
Topology	Step-Up (Boost)
Internal Switch(s)	Yes
Number of Outputs	1
Voltage - Supply (Min)	2.7V
Voltage - Supply (Max)	5.5V
Voltage - Output	-

Current - Output / Channel	750mA (Switch)
Frequency	1.2MHz
Dimming	PWM
Applications	Backlight
Operating Temperature	-40°C ~ 85°C (TA)
Mounting Type	Surface Mount
Package / Case	SOT-23-6 Thin, TSOT-23-6
Supplier Device Package	TSOT-23-6
