HCPL-6651

In Stock: 3,362
HCPL-6651 - Broadcom Limited - Optoisolators - Logic Output
REF: HCPL-6651 Broadcom Limited
HCPL-6651

Broadcom Limited

OPTOISO 1.5KV OPEN COLL 16FLATPK

HCPL-6651 is a Optoisolators - Logic Output manufactured by Broadcom Limited. OPTOISO 1.5KV OPEN COLL 16FLATPK. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 125°C, voltage - supply 4.5V ~ 5.5V, package / case 16-Flatpack.

Datasheet Request a Quote

In Stock: 3,362

Tiered Pricing USD
1+ $166.9400 —
10+ $152.2310 -9% BEST

Specifications

18 parameters
Product StatusActive
Number of Channels4
Inputs - Side 1/Side 24/0
Voltage - Isolation1500VDC
Common Mode Transient Immunity (Min)1kV/µs
Input TypeDC
Output TypeOpen Collector, Schottky Clamped
Current - Output / Channel25 mA
Data Rate10MBd
Propagation Delay tpLH / tpHL (Max)100ns, 100ns
Rise / Fall Time (Typ)35ns, 35ns
Voltage - Forward (Vf) (Typ)1.5V
Current - DC Forward (If) (Max)20mA
Voltage - Supply4.5V ~ 5.5V
Operating Temperature-55°C ~ 125°C
Mounting TypeSurface Mount
Package / Case16-Flatpack
Supplier Device Package16-Flatpack
