Name: SM8SF24A-Q
Brand: Bourns Inc.
SKU: SM8SF24A-Q
Price: 3.63 USD
Availability: InStock

REF: SM8SF24A-Q Bourns Inc.

SM8SF24A-Q

TVS DIODE 24VWM 38.9VC 2DFN

SM8SF24A-Q is a TVS - Diodes manufactured by Bourns Inc.. TVS DIODE 24VWM 38.9VC 2DFN. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 175°C (TJ), package / case 2-LDFN.

Datasheet Request a Quote

In Stock: 8,570

Tiered Pricing USD

1+ $3.6300 —

10+ $2.3740 -35%

100+ $1.6588 -54% BEST

Specifications

16 parameters

Product Status	Active
Type	Zener
Unidirectional Channels	1
Bidirectional Channels	-
Voltage - Reverse Standoff (Typ)	24V
Voltage - Breakdown (Min)	26.7V
Voltage - Clamping (Max) @ Ipp	38.9V
Current - Peak Pulse (10/1000µs)	180A

Power - Peak Pulse	7000W (7kW)
Power Line Protection	No
Applications	Automotive
Capacitance @ Frequency	-
Operating Temperature	-55°C ~ 175°C (TJ)
Mounting Type	Surface Mount
Package / Case	2-LDFN
Supplier Device Package	2-DFN (8.1x10.5)
