LTC7000IMSE-1#TRPBF

In Stock: 8,097
LTC7000IMSE-1#TRPBF - Analog Devices Inc. - PMIC - Gate Drivers
REF: LTC7000IMSE-1#TRPBF Analog Devices Inc.
LTC7000IMSE-1#TRPBF

Analog Devices Inc.

IC GATE DRVR HIGH-SIDE 16MSOP

LTC7000IMSE-1#TRPBF is a PMIC - Gate Drivers manufactured by Analog Devices Inc.. IC GATE DRVR HIGH-SIDE 16MSOP. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C (TJ), voltage - supply 3.5V ~ 135V, package / case 16-TFSOP (0.118", 3.00mm Width), 12 Leads, Exposed Pad.

Datasheet Request a Quote

In Stock: 8,097

Specifications

15 parameters
Product StatusActive
Driven ConfigurationHigh-Side
Channel TypeSingle
Number of Drivers1
Gate TypeN-Channel MOSFET
Voltage - Supply3.5V ~ 135V
Logic Voltage - VIL, VIH1.8V, 1.7V
Current - Peak Output (Source, Sink)-
Input TypeNon-Inverting
High Side Voltage - Max (Bootstrap)135 V
Rise / Fall Time (Typ)90ns, 40ns
Operating Temperature-40°C ~ 125°C (TJ)
Mounting TypeSurface Mount
Package / Case16-TFSOP (0.118", 3.00mm Width), 12 Leads, Exposed Pad
Supplier Device Package16-MSOP-EP
