Name: AD8605ACB-REEL
Brand: Analog Devices Inc.
SKU: AD8605ACB-REEL
Availability: InStock

REF: AD8605ACB-REEL Analog Devices Inc.

AD8605ACB-REEL

IC OPAMP GP R-R CMOS PREC 5WLCSP

AD8605ACB-REEL is a Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps manufactured by Analog Devices Inc.. IC OPAMP GP R-R CMOS PREC 5WLCSP. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, package / case 5-UFBGA, WLCSP, current - supply 1mA.

Datasheet Request a Quote

In Stock: 8,943

Specifications

17 parameters

Product Status	Obsolete
Amplifier Type	General Purpose
Number of Circuits	1
Output Type	Rail-to-Rail
Slew Rate	5V/µs
Gain Bandwidth Product	10 MHz
-3db Bandwidth	-
Current - Input Bias	0.2 pA
Voltage - Input Offset	80 µV

Current - Supply	1mA
Current - Output / Channel	80 mA
Voltage - Supply Span (Min)	2.7 V
Voltage - Supply Span (Max)	5.5 V
Operating Temperature	-40°C ~ 125°C
Mounting Type	Surface Mount
Package / Case	5-UFBGA, WLCSP
Supplier Device Package	5-WLCSP (0.9x1.29)
