Name: AD203SN
Brand: Analog Devices Inc.
SKU: AD203SN
Price: 302.18 USD
Availability: InStock

REF: AD203SN Analog Devices Inc.

AD203SN

IC OPAMP ISOLATION 1 CIRC 11DIP

AD203SN is a Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps manufactured by Analog Devices Inc.. IC OPAMP ISOLATION 1 CIRC 11DIP. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 125°C, package / case 38-DIP (0.500", 12.70mm), 11 Leads, current - supply 20mA.

Datasheet Request a Quote

In Stock: 2,465

Specifications

17 parameters

Product Status	Active
Amplifier Type	Isolation
Number of Circuits	1
Output Type	-
Slew Rate	0.5V/µs
Gain Bandwidth Product	10 kHz
-3db Bandwidth	-
Current - Input Bias	30 pA
Voltage - Input Offset	5 mV

Current - Supply	20mA
Current - Output / Channel	4 mA
Voltage - Supply Span (Min)	12 V
Voltage - Supply Span (Max)	15 V
Operating Temperature	-55°C ~ 125°C
Mounting Type	Through Hole
Package / Case	38-DIP (0.500", 12.70mm), 11 Leads
Supplier Device Package	11-PDIP
