MAX4456CPL+

In Stock: 2,914
MAX4456CPL+ - Analog Devices Inc./Maxim Integrated - Interface - Analog Switches - Special Purpose
REF: MAX4456CPL+ Analog Devices Inc./Maxim Integrated
MAX4456CPL+

Analog Devices Inc./Maxim Integrated

IC VIDEO CROSSPOINT SWITCH 40DIP

MAX4456CPL+ is a Interface - Analog Switches - Special Purpose manufactured by Analog Devices Inc./Maxim Integrated. IC VIDEO CROSSPOINT SWITCH 40DIP. Key specifications: mounting type Through Hole, operating temperature 0°C ~ 70°C (TA), package / case 40-DIP (0.600", 15.24mm).

Datasheet Request a Quote

In Stock: 2,914

Specifications

14 parameters
Product StatusObsolete
ApplicationsVideo
Multiplexer/Demultiplexer Circuit8:8
Switch Circuit-
Number of Channels1
On-State Resistance (Max)-
Voltage - Supply, Single (V+)-
Voltage - Supply, Dual (V±)±4.5V ~ 5.5V
-3db Bandwidth65MHz
FeaturesBi-Directional, Buffered, T-Switch Configuration
Operating Temperature0°C ~ 70°C (TA)
Mounting TypeThrough Hole
Package / Case40-DIP (0.600", 15.24mm)
Supplier Device Package40-PDIP
